| Operation Class | Class D |
| Number of Channels | 04 |
| Maximum Power | @ 14.4 VDC - 2 OHMS: 2000W RMS (4 x 500W RMS) @ 14.4 VDC - 4 OHMS: 1300W RMS (4 x 325W RMS) 2 Bridged Channels (2 x 1000RMS) at 4 ohms |
| Input Sensitivity | 250mV |
| Frequency Response | 8Hz to 20KHz (-3dB) |
| Crossover High Pass (HPF) | 90Hz (-12dB/8th) Fixed |
| Crossover Low Pass (LPF) | 90Hz (-12dB/8th) Fixed |
| Protection System | Output overload |
| Maximum Music Consumption | 100A |
| Maximum Consumption in Sinusoidal Signal | 200A |
| Dimensions(H X W X D) | 10.55" x 2.83" x 9.64" |
| Weight | 7.42lbs |
