System Specifications

• Frequency Response(-3dB) 30Hz-150hz
• Frequency Range(-10dB) 25Hz-200hz
• Max Peak SPL(calculated) 129dB
• Max Peak SPL(measured) 126dB
• Transducer Specifications
• Diameter 18 in / 457mm
• Voice Coil Diameter 3.0 in / 76
• Cone material: Paper
• Magnet material: Ferrite
• Power Amplifiers Rated Power 500 watts rms 1000watts Peak
• Rated THD <0.1%
• Cooling Convection Extrusion
• Design Class D
• Input/output
• Input Type Female XLR Balanced Differential(stereo left/right)
• Input Impedance 47k ohms
• Full range(Link)/High Pass output(x-over): Male XLR Balanced
• Full range out put: Select Link out put
• High Pass out Put: Select X-over out put
• X-over button: Cut low frequency, 90Hz/120Hz selectable,
• Phase adjustable: 0~180
• Maximum Input Level To -3dB
• Electronic Crossover
• Crossover Type: 24db/Oct.
• Linkwitz-Riley
• Crossover Frequency: 90Hz or 120Hz
• Enclosure Construction Features
• Basic Design Asymmetrical Rectangle
• Material Polypropylene
• Finish Black textured finish
• Handles One on each side
• Grille Perforated metal with weather-resistant coating
• Protection Features
• Over-excursion Protection: 40Hz 24 db/Oct.
• Butterworth High Pass Filter
• Thermal Protection: Amplifier mute, auto reset
• Driver Protection: Peak/RMS Limiter
• Display LEDs Signal, Power, Limit
• AC Power Requirements
• Power Consumption 120 watts with musical program
• and LIMIT LED blinking
• US 120 VAC,60Hz Recommended Amperage Service 2.5 amps

Physical Properties

• Height 26.1 in/ 663mm
• Width 22.0 in/ 560mm
• Depth 30.1 in/764mm
• Weight 106 lb/46.7kg
